Orbea Wild M-Series 2026

2026 Orbea Wild M20, M10, M-TEAM, M-LTD – Key Features

The M20 feels playful and surprisingly nimble for its weight—great fun on flowing trails and fluid climbs, with accessible power that hooks you in without overwhelming you.
M10 delivers crisper feedback, more composure on technical terrain, and a poise that feels race-ready without being intimidating, even as your daily rider.
The M‑TEAM sharpens that further, teamed with Factory‑level suspension, it feels more planted and responsive under aggressive inputs, dancing through rough tracks with precision and energy The M‑LTD is a downhill dominator—its latest Bosch CX‑Race motor, lightweight carbon build, and RACE mode deliver explosive acceleration and unwavering composure on steep, gnarly descents, making it feel like a pro‑level gravity

Frame & Suspension

• Frame: Orbea Wild OMR 2025, 29" wheels, Concentric Boost 12x148
• M20: Fox Float X Performance Trunnion 2-Pos Evol LV custom tune 205x65mm
  Fork: RockShox ZEB Base-A2 DebonAir+ 170 E-MTB specific 15X110 Boost
• M10: Fox Float X Performance Trunnion 2-Pos Evol LV custom tune 205x65mm
  Fork: Fox 38 Float Performance 170 Grip 3-Pos QR15x110
• M-TEAM: Fox Float X2 Factory Trunnion 2-Pos Adjust Kashima custom tune 205x65mm
  Fork: Fox 38 Float Factory 170, Grip X2, QR15x110, Kashima
• M-LTD: Fox Float X2 Factory Trunnion 2-Pos Adjust Kashima custom tune 205x65mm
  Fork: Fox 38 Float Factory 170, Grip X2, QR15x110, Kashima

Motor & Battery

• Bosch Performance Line CX Gen 5 motor (85 Nm)
• 750 Wh battery (M20, M10, M-Team)
• 600 Wh battery (M-LTD)
• Bosch Smart System: app support, connectivity, custom modes

 Components

• M20: Shimano SLX M7100 SGS Shadow Plus
  Wheels: Race Face AR 30c Tubeless Ready
  Brakes: Shimano MT420 Hydraulic Disc
• M10: Shimano XT M8100 SGS Shadow Plus
  Wheels: DT Swiss H-1900 Spline 30c TLR 15/110mm 6-Bolt
  Brakes: Shimano XT Hydraulic Disc
• M-TEAM: Shimano XT M8260 SGS
  Wheels: Oquo Mountain Control MC32TEAM POWER
  Brakes: Shimano XT Hydraulic Disc
• M-LTD: Shimano XTR M9260 12s
  Wheels: Oquo Mountain Control MC32LTD POWER
  Brakes: Shimano XTR Hydraulic Disc
• Tyres: Maxxis Assegai 2.50" 60TPI 3CG/EXO+/TR MaxxGrip - Maxxis Minion 2.40" 120 TPI 3CT/DD/TR MaxxTerra
• Dropper post: OC Mountain Control MC22, 31.6mm, Dropper
